Sinomtp Lg936 Wheeled Front End Loader 3000kg With 3100mm Maximum Dump Height

Product Categories

Shandong Sinomtp Construction Equipment Company Limited

Contact Now

Name: Sinomtp Lg936 Wheeled Front End Loader 3000kg With 3100mm Maximum Dump Height
Brand: SINOMTP
Price: 1 USD

Brand Name : SINOMTP

Model Number : LG936

Certification : ISO/CCC/BV

Place of Origin : China

MOQ : 1 unit

Price : negotiation

Supply Ability : 100 units per month

Delivery Time : 35 days after payment

Packaging Details : NUDE

BUCKET CAPACITY : 1.7M3

maximum dump height : 3100mm

ENGINE : WEICHAI DEUTZ

rated loading : 3000kg

maximum torque : 500N.m

min fuel-consume ratio : ≤210g/kw.h

Contact Now

SINOMTP LG936 WHEEL FRONT END LOADER 3000KG WITH 3100mm Maximum Dump Height

SPECIFICATION:

Performance	1	rated loading	3000kg
	2	overall weight	9600kg
	3	rated bucket capacity	1.7
	4	maximum tractive force	97KN
	5	maximum breakout force	127KN
	6	maximum grade ability	30℃
	7	maximum dump height	3100mm
	8	maximum dump reach	1006mm
	9	overall dimension (L×W×H)	6890×2430×3070mm
	10	minimum turning radius	5097mm
Engine	11	model	Deutz WP6G125E22
	12	type	lnline water cooled, four stroke
	13	No. of cylinder-bore/stroke	6—108×125mm
	14	rated power	92kw
	15	maximum torque	500N.m
	16	min fuel-consume ratio	≤210g/kw.h
Transmission system	17	torque converter	YJ315—x
	18	gearbox mode	Power shift normally engaged straight gear
	19	gear shift	4forward shift 2 reverse shift
	20	maximum speed	40km/h

DESCRIPTION:
